Psa Medical Oxygen Plant For Medical Industry Or Hospital Usage
Détails sur le produit:
| Lieu d'origine: | Chine |
| Nom de marque: | KERONG GAS |
| Certification: | ISO13485，ISO9001 |
| Numéro de modèle: | RDC |
Conditions de paiement et expédition:
| Quantité de commande min: | 1 pièce |
|---|---|
| Prix: | negotiable |
| Détails d'emballage: | boîte en bois |
| Délai de livraison: | 8 semaines |
| Conditions de paiement: | LC, T/T, Western Union, MoneyGram |
| Capacité d'approvisionnement: | 1000pcs par an |
|
Détail Infomation |
|||
| Nom: | Usine médicale de l'oxygène de PSA | Pureté: | 90% à 99,5% |
|---|---|---|---|
| Teneur en huile: | Ne contenant pas de pétrole | Matériel: | Acier inoxydable ou acier au carbone |
| Capacité: | 5Nm3/h à 60Nm3/h | Pression: | Réglable |
| Mettre en évidence: | PSA medical oxygen plant for hospitals,medical oxygen generator with warranty,PSA oxygen plant for medical industry |
||
Description de produit
Psa Medical Oxygen Plant For Medical Industry Or Hospital Usage
Product description
Our PSA Medical Oxygen Plant for Medical Industry or Hospital Usage is designed to provide a continuous and reliable on-site supply of medical-grade oxygen for hospitals, clinics, and healthcare facilities. Utilizing advanced Pressure Swing Adsorption (PSA) technology, the plant efficiently separates oxygen from compressed air, delivering oxygen purity of 93% ±3% in accordance with medical standards. The fully automatic system features intelligent PLC controls, real-time oxygen purity monitoring, and stable pressure regulation for safe and dependable operation. Energy-efficient, low-maintenance, and easy to install, this PSA oxygen plant offers a cost-effective alternative to oxygen cylinders and liquid oxygen, ensuring uninterrupted oxygen availability for critical healthcare applications.
Technical Parameters
● Purity——93%±3% or with the oxygen purifier can get maximum 99.5%
● Pressure——0.3~0.6 Mpa or with the booster to get 30Mpa or more
● Atmospheric dew point——≤－40℃ or more
| Item | Model | Oxygen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) |
| 1 | KRO-1-95 | 1 | 95%±1% | 0.25 |
| 2 | KRO-2-95 | 2 | 95%±1% | 0.50 |
| 3 | KRO-3-95 | 3 | 95%±1% | 0.75 |
| 4 | KRO-5-95 | 5 | 95%±1% | 1.25 |
| 5 | KRO-10-95 | 10 | 95%±1% | 2.50 |
| 6 | KRO-15-95 | 15 | 95%±1% | 3.75 |
| 7 | KRO-20-95 | 20 | 95%±1% | 5.00 |
| 8 | KRO-25-95 | 25 | 95%±1% | 6.25 |
| 9 | KRO-30-95 | 30 | 95%±1% | 7.50 |
| 10 | KRO-35-95 | 35 | 95%±1% | 8.75 |
| 11 | KRO-45-95 | 45 | 95%±1% | 11.25 |
| 12 | KRO-50-95 | 50 | 95%±1% | 12.50 |
| 13 | KRO-60-95 | 60 | 95%±1% | 15.00 |
Featured Function
Online monitoring of oxygen purity, pressure, flow rate and dew point.
Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
Air dryer and air filters automatic drainer discharge.
Automatic warning of spare parts replacement.
Remote control / fully automatic
Molecular sieve automatic compaction
Pneumatic valve switching by programmable controller automatic control
The IPC, DCS, the specific configuration of other specific programs
Factory Certificates
FAQ
Q: Are you a factory or a trading company?
A:We are a factory over 20 years industrial experience.
Q: Do you offer OEM service?
A: Yes, we can customize it as your request.
Q: What is your lead time?
A: About 60~90 days after receiving deposit.
Q: What certificates do you have?
A: We have ASME, CE, ISO9001-2015, ISO13485 for medical oxygen generator. And we can apply for specific certificate for different country such as SONCAP for Nigeria, SASO for Saudi Arabia, etc
Q: What about the warranty?
A: Beyond warranty period(For 12-Months against any manufacturing defect from the date equipment acceptance after commissioning or 18-months from the time of the delivery whichever comes first),supplier will provide spare parts, accessories, easily damaged parts via preferential price.
Q:What service do you offer?
A: Pre-sales service, in-sales service, after-sales service. If you become our local distributor, we can introduce end-customers to purchase from you.
Q:Which port is near to you?
A: Qingdao port or Tianjin port. And we can arrange to deliver Guangzhou, Shanghai, Urumqi, or other Chinese cities, too.
Q:Could you offer Origin Certification.
A: we can do as your request.
