Low Emission Ammonia Dissociation Unit With Over Pressure Protection
Détails sur le produit:
| Lieu d'origine: | Chine |
| Nom de marque: | KERONG GAS |
| Certification: | ISO9001 |
| Numéro de modèle: | ANH, NHP |
Conditions de paiement et expédition:
| Quantité de commande min: | 1 pièce |
|---|---|
| Prix: | negotiable |
| Détails d'emballage: | boîte en bois |
| Délai de livraison: | 8 semaines |
| Conditions de paiement: | LC, T/T, Western Union, MoneyGram |
| Capacité d'approvisionnement: | 1000pcs par an |
|
Détail Infomation |
|||
| Nom: | Unité de dissociation de l'ammoniac | Catalyseur: | Catalyseur de nickel |
|---|---|---|---|
| Point de rosée: | -70 ℃ | Matériel: | Acier inoxydable ou acier au carbone |
| Capacité: | 5Nm3/h à 250Nm3/h | Pression: | 00,5 bar ou plus |
| Mettre en évidence: | low emission ammonia cracker unit,ammonia dissociation unit with over pressure protection,industrial ammonia cracker with safety features |
||
Description de produit
Low Emission Ammonia Dissociation Unit With Over Pressure Protection
Product description
Our Low Emission Ammonia Dissociation Unit with Over Pressure Protection is engineered to provide a safe, efficient source of dissociated ammonia gas for heat treatment, brazing, annealing, and metallurgical applications. Using advanced thermal dissociation technology, it converts ammonia into a hydrogen-nitrogen protective atmosphere while minimizing emissions for environmentally responsible operation. The system is equipped with over-pressure protection, ensuring safe performance under varying load conditions and preventing equipment damage. Fully automatic with precise temperature and pressure control, it delivers stable, continuous gas output with high efficiency. Built with durable, heat-resistant materials, this unit offers reliable operation, long service life, and low maintenance for industrial applications.
Technical Parameters
Capacity: 5-250Nm³/h
Dew point :-70 ℃
Oxygen content: less than 3ppm
Ammonia content: less than 3ppm
| Model | Capacity | Power consumption | Liquid ammonia consumption | Cooling water consumption | Dimensions |
| (Nm3/h) | (KW) | kg/hr | m3/hr | mm | |
| ANH-NHP-5 | 5 | 6.5 | 1.89 | N/A | 1400*1180*1600 |
| ANH-NHP-10 | 10 | 13 | 3.79 | N/A | 1440*1340*1600 |
| ANH-NHP-20 | 20 | 24 | 7.58 | 0.2 | 2200*1435*1800 |
| ANH-NHP-30 | 30 | 34 | 11.36 | 0.2 | |
| ANH-40 | 40 | 36 | 15.15 | 0.25 | 1870*2065*2570 |
| NHP-40 | 40 | 3 | N/A | 1530*880*2010 | |
| ANH-50 | 50 | 44 | 18.94 | 0.25 | 1870*2065*2570 |
| NHP-50 | 50 | 3 | N/A | 1530*860*2010 | |
| ANH-60 | 60 | 52 | 22.73 | 0.25 | 1870*2065*2570 |
| NHP-60 | 60 | 3 | N/A | 1530*860*2010 | |
| ANH-70 | 70 | 58 | 26.52 | 0.42 | 1870*2065*2570 |
| NHP-70 | 70 | 6 | N/A | 1480*900*2050 | |
| ANH-80 | 80 | 64 | 30.30 | 0.42 | 1870*2065*2570 |
| NHP-80 | 80 | 6 | N/A | 1480*900*2050 | |
| ANH-90 | 90 | 88 | 34.09 | 0.65 | 1990*2295*2580 |
| NHP-90 | 90 | 6 | N/A | 1800*1000*2050 | |
| ANH-100 | 100 | 83 | 37.88 | 0.65 | 1990*2295*2580 |
| NHP-100 | 100 | 6 | N/A | 1800*1000*2050 | |
| ANH-110 | 110 | 104 | 41.67 | 0.65 | 1990*2295*2580 |
| NHP-110 | 110 | 6 | N/A | 1800*1000*2250 | |
| ANH-120 | 120 | 104 | 45.45 | 0.65 | 1990*2295*2580 |
| NHP-120 | 120 | 6 | N/A | 1800*1000*2250 | |
| ANH-140 | 140 | 117 | 53.03 | 0.85 | 1990*2295*3078 |
| NHP-140 | 140 | 9 | N/A | 1800*1000*2450 | |
| ANH-150 | 150 | 138 | 56.82 | 0.85 | 1990*2295*3078 |
| NHP-150 | 150 | 9 | N/A | 1800*1000*2650 | |
| ANH-160 | 160 | 138 | 60.61 | 0.85 | 1990*2295*3078 |
| NHP-160 | 160 | 9 | N/A | 1800*1000*2650 | |
| ANH-180 | 180 | 155 | 68.18 | 1.15 | 2290*2620*3100 |
| NHP-180 | 180 | 13.5 | N/A | 2150*1000*2785 | |
| ANH-200 | 200 | 155 | 75.76 | 1.15 | 2290*2620*3100 |
| NHP-200 | 200 | 13.5 | N/A | 2150*1000*2595 | |
| ANH-250 | 250 | 196 | 94.70 | 1.3 | 2520*2775*3150 |
| NHP-250 | 250 | 13.5 | N/A | 2150*1000*2600 |
